Surface textures

A texture is just a tiled image file that appears on a surface or a whole block. When double clicking on a texture in the [Textures] window, it is applied to the currently selected block.

Textures can be selected either from WAD texture collections, or from image folders on your PC. Any number of WADs or folders can be added to your map for selecting textures from them. For adding a WAD, right click on [Presets / Textures] and select [Add WAD]. For adding a folder with images, right click on [Presets / Textures] and select [Add Folder]. The WAD or the folder then appears in the [Textures] window, and the textures inside are available for the block surfaces.

You can import your own textures into a WAD collection. For this, first add the WAD as described above, and open it in the [Textures] window. Right click inside the WAD and select [Add Texture]. Then navigate to the image file that you want to add. Please note that you can't use just any image; surface textures images must fulfil some requirements listed below:

Image formats for surface textures

The image format does matter. For high quality, use the TGA 24-bit format; for low memory consumption and fast rendering, use the DDS DXT1 format. PCX or BMP textures are internally stored in medium quality 16 bit color depth. 8 bit (256 color) palettized PCX and BMP textures are also supported for legacy reasons, but must share the same color palette per level, and have low quality. The first color of the palette (color #0) must always be black, the last color (color #255) must always be white. If you don't know what a palette is, or if you don't need to support very old PCs, don't use 8 bit textures.

PCX and BMP textures can be automatically converted to the DDS 4-bit compressed format on level loading depending on a script setting (d3d_texdepth). The 4 bit format reduces the texture quality further and increases the level loading time due to the conversion process, but can save a lot of video memory. Native DDS images can be created with the DirectX Texture Tool, with ATI's Compressonator or with a DDS plugin for Photoshop. They can contain mipmaps and use a compressed 4-bit surface format (DXT1) for saving video memory at the expense of image quality. They have the advantage of small level file sizes, fast loading, and fast rendering, and are the preferred format for all medium quality surface textures.

4 mipmap levels for TGA, PCX, and BMP textures are automatically created when compiling the level. Mipmaps increase both the rendering speed and the visual quality of far away textures. DDS textures contain their own mipmaps, so no extra mipmaps are created for them.

An alpha transparency channel is contained in 32 bit TGA textures and on DXT2..DXT5 DDS textures. Surface textures must not be transparent, but alpha channels can be used for shader effects, for instance for a specular map. For transparent objects in the map, use entities.

Sky Textures

A texture with a name beginning with "sky" can be assigned to the walls of the sky box around the level. The texture proportions determine the kind of sky mapping. If it's width is twice it's height, it's first half is used for moving clouds below a sky dome and it's second half is used for the sky dome texture (see image).

If it's width is six times it's height, the texture is used for a sky cube around the level (see image below). For displaying the sky cube in the 3D window, activate 'Sky Cube' in Preferences -> Advanced.

More complicated multi-layered skies can be defined by script; see the sky entity section for details.

Normal Maps

If a texture name ends with "_n" , the texture is used as a normal map for a base texture with the same name. For instance, a texture named "stones2_n" is expected to contain a normal map for the texture "stones2". The normal map needs not be applied to a surface - it's automatically included with the texture. But for using it you need to apply a material with a normal mapping shader (for details see How To Appy Shaders). Several normal mapping materials are included in the mtlFX.c library. If a normal map has an alpha channel, it is used for a height map in the parallax and occlusion shaders.

Memory Requirement

Video memory is consumed by the textures as well as by the shadow mapped surfaces in the map. Due to the mipmaps, each TGA texture pixel consumes about 6 bytes of video memory. Every 64 surface pixels consume 1..4 additional bytes for the shadow maps (depending on the light resolution). On levels with huge surface areas, the shadow maps can easily consume several 100 MB. For reducing the shadow maps, prevent shading by using the Flat surface flag on large surfaces. If the video memory available on the 3D card is exceeded, the game will still run, but will swap textures, which may result in slow rendering and sudden 'jerks' at some places in the map. You can check the current video memory consumption through the [F11] engine panel.
